Electrical Information
|
|
Model No.
|
HB43-150
|
HB43-200
|
|
Power Consumption(±5%)
|
150W-120W-100W-80W Adjustable
|
200W-150W-120W-100W Adjustable
|
|
Power Supply
|
LIFUD
|
|
Input Voltage
|
220-240VAC , 50 / 60 Hz
|
|
Power Factor
|
>0.92
|
|
Surge Protection
|
4kV line-line, 6kV line-earth
|
|
Driver Type
|
Constant Current (CC)
|
|
Control
|
Dimmable and Non-dimmable , Microwave Motion Sensor
PIR Sensor
|
|
Optic Information
|
|
LED Type
|
LED 3030
|
|
Luminous Flux (±10%)
|
21000lm-25500lm
|
28000lm-34000lm
|
|
Efficacy (5000K Ra70)
|
140lm/W-170lm/W
|
|
Correlated Color Temperature
|
5000K (3000K, 4000K optional)
|
|
Color Rendering Index
|
Ra70 (Ra80 optional)
|
|
Beam Angle
|
H00130 (Wide/Medium/Narrow adjustable)
|
|
UGR level
|
28
|
|
Dimentions and Mount
|
|
Product Dimension
|
φ320×167mm
|
|
Luminaire Net Weight
|
3.0 ± 0.3kg
|
|
Export Carton Size
|
380x380x225mm
|
|
Gross Weight
|
4.3±0.3kg
|
|
Mounting Option
|
Loop Hanging
Ceiling Mounting
|
|
Material
|
Aluminum Alloy
Polycarbonate Optical Lens
|
|
Finish
|
Powder Coating
|
|
Fixture Color
|
Black
|
|
EPA
|
NA
|
|
IK Rating
|
IK07
|
|
IP Rating
|
IP42
|
|
Lifespan and Warranty
|
|
Operating Temperature
|
Normal : -30°C to + 50°C (-22°F to 122°F)
Sensor version : 0°C to + 50°C (32°F to 122°F)
|
|
Life Time of LED
@Ta=25°C
|
80000 Hrs-L80
127000 Hrs-L70
|
