Electrical Information
|
Model No.
|
BL-HB44-100
|
BL-HB44-120
|
BL-HB44-150
|
BL-HB44-200
|
Power Consumption (±5%)
|
100W
|
120W
|
150W
|
200W
|
Power Supply
|
LIFUD
|
Input Voltage
|
200-240VAC, 50 / 60 Hz
|
Power Factor
|
>0.95
|
Surge Protection
|
4kV line-line, 6kV line-earth
|
Driver Type
|
Constant Current (CC)
|
Control
|
Dimmable and Non-dimmable, Microwave Motion Sensor
PIR Sensor
|
Optic Information
|
LED Type
|
LED 2835
|
Luminous Flux (±10%)
|
15000lm
|
18000lm
|
22500lm
|
30000lm
|
Efficacy (5000K Ra70)
|
150lm/W
|
Correlated Color Temperature
|
5000K (3000K, 4000K optional)
|
Color Rendering Index
|
Ra80
|
Beam Angle
|
H00126, H00123, H00124
|
H00108, H00115,
|
UGR level
|
>25.6
|
>25.8
|
Dimentions and Mount
|
Product Dimension
|
φ293X167mm
|
φ298×167mm
|
φ364×166mm
|
Luminaire Net Weight
|
2.27±0.3kg
|
2.3±0.3kg
|
2.9±0.3kg
|
Export Carton Size
|
264x264x220mm
|
430×430×210mm
|
Gross Weight
|
3.0±0.3kg
|
3.3±0.3kg
|
4.5±0.3kg
|
Mounting Option
|
Loop Hanging
Ceiling Mounting
|
Material
|
Aluminum Alloy
Polycarbonate Optical Lens
|
Finish
|
Powder Coating
|
Fixture Color
|
Black
|
EPA
|
NA
|
IK Rating
|
IK08
|
IP Rating
|
IP65
|
Lifespan and Warranty
|
Operating Temperature
|
Normal : -30°C to + 50°C (-22°F to 122°F)
Sensor version : 0°C to + 50°C (32°F to 122°F)
|
Life Time of LED
@Ta=25°C
|
64,000 hrs-L80
101,000 hrs-L70
|
